Dimensions
尺寸標示與詳細規格比較
| Order No. 订购编号 | Range ∅d 夹持范围 | ∅D | L | L1 | Tool Clamping Depth L2 刀具夹持深度 | Nut 螺帽 | Screw 调整螺丝 | Collet 筒夹 | Wrench 扳手 |
|---|---|---|---|---|---|---|---|---|---|
| BT30N PFK10-060S | 1.75~10.0 | 27.5 | 60 | 38 | 30~50 | CAP-PFK10S | PFK-M12 | SK10-P | PHS-10-TW275 |
| BT30N PFK16-060S | 2.75~16.0 | 40 | 60 | 38 | 40~54 | CAP-PFK16S | PFK-M18 | SK16-P | PHS-20-RO400 |
備註 Remarks
- 需配合3µ P筒夹 With 3µ P Grade Collet
